| 원래 장소: | 중국 |
| 브랜드 이름: | YUHONG |
| 인증: | ISO13485:2016 |
| 모델 번호: | SUS304 |
| 최소 주문 수량: | 50kg |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 상자 상자, 플라스틱 상자, 합판 케이스 |
| 배달 시간: | 15-45 근무일 |
| 지불 조건: | t/t, l/c |
| 공급 능력: | 연간 130 억 조각 |
| 제품 이름: | 의학 스테인레스 강 모세관 | 모세관 튜브 표준: | ISO9626 : 2016 (의료), ASTM A269 (산업) |
|---|---|---|---|
| 모세관 튜브 재료: | SUS304, AISI304, 1.4301, X5CRNI18-9, 06CR19NI10 | 모세관 외부 직경: | 0.15mm-3.4mm 또는 필요에 따라 |
| 외경 허용 오차: | 일반적으로 ± 0.005mm 내지 ± 0.013mm 이내 | 벽 두께 허용한도: | 일반적으로 ± 0.005mm 내지 ± 0.010mm 이내 |
| 모세관 튜브 길이: | 2 미터 또는 바늘 튜브 길이로 자릅니다 | 모세관 튜브 표면 마감: | 우아한 |
Medical Stainless Steel 304 Precision Capillary Tube For Hypodermic Needles ISO9626 1.4301
Medical grade stainless steel micro capillary tubes are small-diameter hollow high-precision tubes made from stainless steel 304 grade, which are usually used in medical devices and equipments, like injection needle tubes, infusion needle tubes, IV cannulas, catheters, etc.. These capillary tubes are known for their high precision, good durability, good formability, strength, and excellent resistance to corrosion. These stainless steel capillary tubes are not the final needle tubes but they are the essential raw material that medical needle tube manufacturers use. They are cold drawn to highly precise dimensions and undergo rigorous processing to ensure they meet the stringent demands of piercing human skin and delivering or extracting fluids safely.
Our company has manufactured stainless steel capillary tubes for more than 30 years, not only used for medical devices, but also for industrial applications. For medical use, these capillary tubes are usually cut into fixed needle tube length and ground with special bevel needle tips. Our medical capillary tubes are produced according to ISO9626 standard, which have tight dimensional tolerance and good surface. We can also provided based on clients’ detailed tolerance requirements.
Regular Sizes For Hypodermic Usage (Diameter, Wall Thickness, Length):
| Needle Gauge (G) | Outer Diameter (OD) | Common Wall Thickness (WT) | Inner Diameter (ID) |
| 18G | 1.27 mm | 0.20 mm | 0.87 mm |
| 21G | 0.82 mm | 0.13 mm | 0.56 mm |
| 23G | 0.64 mm | 0.11 mm | 0.42 mm |
| 25G | 0.51 mm | 0.08 mm | 0.35 mm |
| 27G | 0.41 mm | 0.07 mm | 0.27 mm |
| 30G | 0.31 mm | 0.06 mm | 0.19 mm |
Length: Capillary tubes are generally supplied in straight lengths, commonly ranging from 1 to 2 meters, which are then cut to the required needle length(18mm, 25mm, 30mm, 32mm, 45mm, etc.).
Key Features Of Medical Capilalry Tubes:
Different Applications Of Stainless Steel Capillary Tubes:
The stainless steel capillary tubes are ideal for numerous medical and non-medical applications:
1. Medical Applications:
2. Industrial & Non-Medical Applications:
