| 원래 장소: | 중국 |
| 브랜드 이름: | YUHONG |
| 인증: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| 모델 번호: | ASTM SB163 N04400 |
| 최소 주문 수량: | 100kg |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 플라스틱 캡 / 우븐과 층 나무로 된 케이스 /Iron Case/ 번들 건 |
| 배달 시간: | 수량에 따라 다릅니다 |
| 지불 조건: | l/c, t/t |
| 공급 능력: | 한 달에 1000 톤 |
| 재료 등급: | UNS N04400 / 모넬 400 | 제품 유형: | 매끄러운 니켈-코퍼 합금 파이프 |
|---|---|---|---|
| 인증 준수: | ASTM SB163, ASME SB163, EN 10204 3.1 | 끝 연결 유형: | 실이 꿰이는 평범한 단부, 경사진 단부 |
| 표면 마감: | 어닐링하고 절인, 연마 | 부식 저항: | 해수, 산, 알칼리 환경 |
| 강조하다: | ASTM SB163 Monel 400 seamless pipe,N04400 nickel alloy pipe EN10204 certified,Monel 400 pipe with 3.1 certification |
||
ASTM SB163 UNS N04400 is a nickel-copper alloy seamless pipe renowned for exceptional corrosion resistance in acidic, alkaline, and marine environments. With high strength, thermal stability (up to 538°C), and superior fabricability, it’s ideal for critical applications in chemical processing, oil & gas, and marine engineering. Manufactured to ASTM SB163 standards, these pipes ensure reliability in extreme conditions.
The corrosion resistance of N04400 stems from its precise nickel-copper balance. Key elements include:
| Element | Content (%) | Element | Content (%) |
|---|---|---|---|
| Nickel (Ni) | 63.0 min | Copper (Cu) | 28.0–34.0 |
| Iron (Fe) | 2.0 max | Manganese (Mn) | 2.0 max |
| Carbon (C) | 0.3 max | Sulfur (S) | 0.024 max |
| Silicon (Si) | 0.5 max |
N04400 alloy is globally recognized under these designations:
| Standard | Equivalent Grade | Standard | Equivalent Grade |
|---|---|---|---|
| UNS | N04400 | EN | NiCu30Fe |
| DIN | 2.4360 | JIS | NW4400 |
| BS | NA 13 | ASME | SB163 |
Meets ASTM SB163 requirements for high strength and ductility:
| Property | Value |
|---|---|
| Tensile Strength | 550 MPa (min) |
| Yield Strength (0.2%) | 240 MPa (min) |
| Elongation (%) | 35% (min) |
| Hardness (Rockwell B) | 90 HRB (max) |
Precision-engineered to ASTM SB163 specifications:
| Parameter | Tolerance |
|---|---|
| Outer Diameter | ±0.8% (OD ≤ 50mm) ±0.5% (OD > 50mm) |
| Wall Thickness | +20% / -0% (Schedules 5S-XXS) |
| Length | +3 mm / -0 mm (Cut Length) |
N04400 pipes excel in corrosive and high-stress environments:
